StarMeta Technology

Fine Pitch LED Screen Small Pixel LED Display

Mini LED Display is designed to take everthing great

* Self Luminous technology, outstanding Full Colors, High Definition .

Exceedingly thin and capable of delivering outstanding viewing angles.

More Economic Cost to produce than 0LED.

Best of all, Mini LED can technically deliver a brighter picture than OLEDs.

Submit wish list

Solution

SHENZHEN StarMata TECHNOLOGY CO.,LTD
wwww.starmeta.tech , Email: starmetat@hotmail.com , Facebook Whats APP : +86 13590171205
Model NO.	SP0.7	SP0.9	COBSP0.9	SP1.25	SP1.5	SP1.8	SP2.5
Pixel Pitch(mm)	0.7	0.9375	0.9375	1.25	1.5625	1.875	2.5
Pixel Matrix Per Sq.m	1590207	1137778	1137778	640000	409600	250000	160000
Pixel Configuration	SMD 3 in 1	MINI 4-in-1	COB Gold	SMD1010	SMD1212	SMD1515	SMD2525
Brightness (nits)	500 cd/m2	500-1200 cd/m2	500-1200 cd/m2	500-1200 cd/m2	500-1200 cd/m2	500-1200 cd/m2	500-1200 cd/m2
Scan	1/30	1/30	1/30	1/45	1/54	1/45	1/30
Module Dimension		150x168.75mm / 0.49x0.55ft
Cabinet Resolution		640x360	640x360	480x270	385x216	320x180	240x135
Refresh Rate (HZ)	≥3840	≥3840	≥2880	≥3840	≥3840	≥3840	≥3840
Cabinet Dimension		600x337.5x48mm / 1.97x1.11x0.16ft
Viewing Angle (H/V)	160°/160°	170°/170°	170°/170°	160°/160°	160°/160°	160°/160°	160°/160°
IP Rate	IP43	IP43	Front IP65 / Rear IP43	IP43	IP43	IP43	IP43
Cabinet Material	Die Casting Aluminum
Cabinet Weight	<7.5KG
Power Con.(W/㎡) (Max / Avg)	550W/180W
Service Access	Front Maintenance
Contrast Ratio	7000:01:00
Frame Frequency	50/60Hz , 120Hz
Grey Scale (bit)	12-24 Bit
Color Temp	2000-9500K
Operation Temperature	-20℃ ~ +60°℃
Input Voltage (AC)	110V / 220V
Certification	CCC CE , UL Power and Cable
